KEXINT FSMA - FSMA Optical Fiber Patch Cord 2.0 3.0mm Single Mode Multimode

Product Categories
SHENZHEN KXIND COMMUNICATIONS CO.,LTD
Contact Now

KEXINT FSMA - FSMA Optical Fiber Patch Cord 2.0 3.0mm Single Mode Multimode

Brand Name : KEXINT

Model Number : FSMA - FSMA

Certification : CE Iso-9001 Ross UL

Place of Origin : CHINA

MOQ : 10+pcs

Price : 1.37+$+piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, MoneyGram

Supply Ability : 1000+PCS+Day

Delivery Time : 8

Packaging Details : box

Fiber Type : SM/MM

Connector Type : SMA 905

Color : Customized Colors

Material : PVC LSZH

Cable Diameter : 2.0mm/3.0mm

Length : 1m/2m/3m/...customized

Package : Carton Box

Operating Temperature (°C) : -40℃~85℃

Contact Now

SMA 905 connector, also known as FSMA connector, was one of the first fiber optic interconnect system that gained industry wide acceptance. It has a screw coupling nut (threaded plug and socket) and holds a single fiber.
SMA fiber optic patch cord is usually multimode. SMA connector’s ferrule is traditionally made of steel (tungsten carbide with copper-nickel alloy insert) although ceramic versions are also available.
SMA905 optical fiber connector or terminal with air gap protection modified SMA905 metal connecting head, equipped large core diameter energy fiber can meet the general semiconductor laser and low power solider laser of output energy laser transmission.Connector can be used within the environmental protection technology of non glue technology,for further increase energy fiber cooling effect and service life,meet the need of laser welding and cutting that high power transmission.
SMA stands for Sub Miniature A. SMA 905 connector has a straight ferrule (3.14mm in diameter), while SMA 906 connector has a stepped ferrule. (ferrule diameter step from 0.118” to 0.089”) The stepped ferrule design allows an alignment sleeve to be used and therefore the SMA 906 connection has lower insertion loss than SMA 905 connection.
APPLICATIONS:
SMA connectors are typically used in medical, surgical, military, industrial, and laser systems. They were once popular but now they are decreasing in popularity. Standard FSMA (Ø=3.175 mm) ber optic connector for LAN, MAN, WAN, Test & Measurement, Industry, Medical and Sensors applications. 1.Food Safety Testing 2.UV for skin care applications 3.Medical light detection device 4.Industrial control, factory automation 5.Industrial silicon, liquid, spectral detection 6.Optical applications experiments on measurement 7.Automobiles and aircraft as well as military applications
FEATURES: 1.Good fatigue resistance 2.Connector diversification options, special custom 3.Large core optical fiber, a variety of optional specifications 4.Fiber 105um-1500um optional 190nm-2500nm wavelength range can be selected
KEXINT FSMA - FSMA Optical Fiber Patch Cord 2.0 3.0mm Single Mode Multimode
Specification
item
value
Model Number
FSMA - FSMA
Type
Optical Fiber Patch Cord
Place of Origin
China
Guangdong
Brand Name
KEXINT
Use
FTTX
Warranty Time
5 YEARS
Network
None
Fiber Type
SM/MM
Connector Type
FSMA
Color
Customized Colors
Material
PVC LSZH
Cable Diameter
2.0mm/3.0mm
Length
1m/2m/3m/...customized
Package
Carton Box
Certification
CE/ROHS/ISO9001
Operating Temperature (°C)
-40℃~85℃

Product Tags:

FSMA FSMA Optical Fiber Patch Cord



Optical Fiber Patch Cord 3.0mm



LSZH Fiber Optical Patch Cord


Quality KEXINT FSMA - FSMA Optical Fiber Patch Cord 2.0 3.0mm Single Mode Multimode wholesale
